Application of Response Surface Methodology Experimental Design to Optimize Tribological Lubrication Characteristics

Abstract

Total Knee Replacement (TKR) has become a standard operation for patients with joint disorders. Despite the fact that the number of procedures is increasing all the time, the short service life of implants remains a persistent concern for researchers. Understanding lubrication may aid in explaining tribological processes that lead to replacements that last well into the third decade of service. Likewise, wear and friction in total knee replacement (TKR) components are among the most common causes of implant failure. As a result, this study will evaluate the feasibility of using the polymer Polylactic Acid (PLA) for cartilage replacement in Total Knee Replacement (TKR) using plant-based oils as lubricants. Furthermore, the modifier will be added to plant-based oils as an additive to make them analogous to human bodily fluids. The present paper is applying the Box-Behnken design to optimize the performance and mechanical responses of bio-lubricants toward Polylactic Acid (PLA) as a tibial insert for cartilage replacement in Total Knee Replacement (TKR). The main objective of this paper is to develop an optimized method for the selection of plant-based oil parameters using Response Surface Methodology (RSM). A three-level three-factor Box-Behnken design (BBD) was used to investigate the interactions between the essential factors comprising load (45 kg to 90 kg), speed (60 rpm, 90 rpm and 360 rpm), and concentration (0ml, 5ml and 10ml) of bio-lubricants to accomplish the indicated prospect of using polymer for cartilage replacement. Canola oil, castor oil, and sunflower seed oil are considered vegetable oils, whereas Hyaluronic Acid (HA) is the friction modifier. The parameters are used to create a Box-Behnken design for predicting lubricant anti-wear qualities stated in terms of coefficient of friction, wear rate and frictional force as determined by the pin-on-disk experimental procedure. As a result, the optimization using RSM successfully interpreted the experimental data, according to the analysis of variance, with coefficients of determination of R2 = 0.91 and adjusted R2 = 0.77. The Coefficient of Friction (CoF) and wear rate were investigated following tribological testing. Castor oil had a lower coefficient of friction than canola and sunflower seed oil, according to the findings. In terms of friction reduction, castor oil surpasses canola and sunflower seed oil.
