Performance of the Savonius Wind Rotor with Two Inner Blades at Low Tip Speed Ratio

Authors

  • Mohanad Al-Ghriybah Department of Renewable Energy Engineering, Faculty of Engineering, Al-Isra University, Amman, Jordan
  • Mohd Fadhli Zulkafli Department of Aeronautical Engineering, Faculty of Mechanical and Manufacturing Engineering, Universiti Tun Hussein Onn Malaysia (UTHM), Johor, Malaysia
  • Djamal Hissein Didane Department of Energy and Thermofluid Engineering, Faculty of Mechanical and Manufacturing Engineering, Universiti Tun Hussein Onn Malaysia (UTHM), Johor, Malaysia
  • Sofian Mohd Department of Aeronautical Engineering, Faculty of Mechanical and Manufacturing Engineering, Universiti Tun Hussein Onn Malaysia (UTHM), Johor, Malaysia

Keywords:

savonius rotor, inner blades, wind turbines, VAWT

Abstract

The Savonius wind turbine is considered as one of the solutions for harvesting the kinetic energy from the wind in the urban areas, due to magnificent features such as, low construction cost, high starting torque, and self-starting ability especially at low wind speed. However, the conventional rotor suffers from low efficiency. Thus, modifying the configuration of the rotor may be an effective solution for providing electricity to the communities with no access to the power grid. Thus, this investigation aims to study numerically the effect of adding two inner blades on the performance of the Savonius wind rotor at low tip speed ratios (TSRs). The simulations are carried out using the two-dimensional simulation with the assist of ANSYS software. For turbulence modelling, the K-?/realizable model was adopted in this study. Power coefficient (Cp) and torque coefficient (Ct) at various TSRs for the rotor are determined under a constant external overlap of 0.018 m. Furthermore, the effect of space between the inner blades was also investigated using three values of spacing. The simulation results show that the rotor with two inner blades performs better than the same rotor without inner blades at all tested TSRs expect at low considered values of 0.2 and 0.25. The heights Cp was 0.188 with 17.1% performance improvement at TSR = 0.4. Furthermore, the numerical results show that Cp values decrease with the decrease of the space between the blades.

Downloads

Published

2021-01-16

How to Cite

Al-Ghriybah, M. ., Zulkafli, . M. F. ., Didane, D. H. ., & Mohd, S. . (2021). Performance of the Savonius Wind Rotor with Two Inner Blades at Low Tip Speed Ratio. CFD Letters, 12(3), 11–21. Retrieved from https://akademiabaru.com/submit/index.php/cfdl/article/view/3220
